Fig. 1.1 is an electron micrograph of a transverse section of palisade mesophyll tissue in the leaf of the flowering plant, Zinnia elegans.
Name the features labelled A, B and C.
A ______
B ______
C ______
Calculate the width of the vacuole across the line X-Y.
Show your working and give your answer to the nearest micrometre ().
answer = ______
The membrane surrounding the vacuole, called the tonoplast, has a fluid mosaic structure.
Describe the structure of this membrane.
Palisade mesophyll cells have very large vacuoles.
Explain how water moves from the xylem in the leaf into these vacuoles.
